Can I swap the FJ 80 MODKIT pull-out fridge for a fridge slide?
No, we don’t offer an integrated fridge slide option. However, our modular drawer system top plates are pre-drilled and reinforced so you can securely mount your own aftermarket fridge slide on top of the FJ 80 drawer unit.
Can the Dometic CD‑30 fridge be installed on the right side?
The Dometic CD‑30 fridge in the FJ 80 modular drawer system is only compatible with a left-side mount due to interior clearance and wiring access.
What configurations are available for the FJ 80 Land Cruiser?
We offer Single Drawer + Fridge and Dual Drawer configurations. Both setups include a built-in accessory box on the rear left side with provisions for mounting batteries, air compressors, or power inverters within your modular drawer system.
How much does the FJ 80 drawer system weigh?
The Dual Drawer configuration weighs 170 lbs, while the Single Drawer + Fridge combination weighs 143 lbs for the drawer plus 42.6 lbs for the Dometic CD‑30 (totaling 185.6 lbs). All weights reflect fully assembled, powder-coated units.
What is the overall height of the system?
The FJ 80 modular drawer system sits 13.125″ above the cargo floor when installed using our base‑plate bars.
Can I stack additional drawers on top?
Yes, custom stacking is possible. Our standard FJ 80 drawer slides and top plates support a secondary drawer layer, but this requires a custom‑made bracket set—please contact us for a stacking solution quote.
Which tie‑down points work best?
We recommend either hardmounting tie downs or using standard L‑track tie‑downs secured into the factory mounting points of your FJ 80. You can purchase our tie down kit here which works great with the system.
Will the drawer system rattle?
No. The FJ 80 modular drawer system uses precision‑machined C‑face walls and anti‑flocking felt tape at all contact zones to eliminate rattles and squeaks.
What’s the max load capacity per drawer?
Each drawer uses genuine Accuride heavy‑duty slides rated up to 600 lbs—ideal for tools, recovery gear, or expedition supplies.
Are other low‑profile fridges compatible?
Only the Dometic CD‑30 has been tested and guaranteed to fit seamlessly within our FJ 80 drawer cavity. Other models may require custom brackets.
How many dividers come with each drawer?
The large drawer includes 4 adjustable dividers (5 total slots), and the small drawer includes 3 adjustable dividers (4 total slots).
Can I buy extra dividers?
Yes—additional drawer dividers are available for purchase on our site. If you have any issues, please contact our support team for assistance.
Can I use my own base plates instead of yours?
For best results, we strongly recommend the complete FJ 80 modular drawer system, including our precision‑curved aluminum base bars for a level mounting plane and perfect interior fit.
Is the system easy to remove?
To uninstall, remove the top plates, lift out the drawers, then unbolt the C‑face walls. The process takes about 15 minutes with basic hand tools.
Do you offer a raw‑aluminum option?
All units ship powder‑coated. If you’d like bare aluminum for custom paint or powder‑coat, contact us before ordering to arrange a raw‑finish build.
How does the base‑plate system mount? Is drilling required?
Most U.S.‑spec FZJ 80 chassis allow a bolt‑in installation with no drilling. Some lifted or accident‑repaired vehicles may require 2–4 small pilot holes. Contact our tech team with your vehicle spec for confirmation.
How quickly can I install or remove the sleeper add‑on?
The FJ 80 sleeper platform installs in under an hour using hand tools. It’s semi‑permanent—not designed for rapid on/off between stops—but can be removed in about 45 minutes if needed.
